The flow measurement can be realized by directly clamping it on the pipe section and connecting it to the power supply. Size > 450[18”] flange type flow meter delivering size > 450[18”]flow meter base and support flow meter should be put.
Clamp-on Ultrasonic Flow Meters Installation Guidelines Rms Engineering
0 to ± 12 m/s (± 30 m/s for high precision sensors).
Clamp on ultrasonic flow meter installation guidelines. We also supply the at600 and df868 ultrasonic flow meters with mcerts certification. If enough grease is not applied or the transducers are not clamped to the wall tightly, the precision of measurement may be effected. The flowmeter consists of a stainless steel sensor rail with two integrated transducers or for large pipe.
Subject to any specific manufacturer’s installation requirements, a minimum length of ten (10) diameters of straight unobstructed rigid pipe1 must be fitted on the intake side of the meter and a minimum of five (5) diameters of straight unobstructed rigid pipe1 on the discharge of the meter. Apply a sufficient amount of grease at the installation area and clamp the transducers tightly on the pipe. • follow all instructions during the installation, operation, and maintenance.
Final flow range determination requires application review Do not connect transducers to rigid conduit. Scope this specification covers the requirements for the design, manufacture, inspection, testing, and supply, installation & commissioning of clamp on type ultrasonic flow.
• in case of horizontal piping, mount the detector within 45° from the. Hardware requirements vary by pipe size and material. Cost savings the ultrasonic sensors are clamped onto the outside of the pipe, thus eliminating the need to dismantle the pipe work and interrupt the process.
The ultrasonic flowmeter can be applied to any type of standard pipe carrying clean or dirty liquids. • record all measurement and configuration data used in flow computer and make this information available for future use. 0 to ± 0.3 m/s velocity (see meter accuracy graph below for more detail) † maximum measuring range:
The sensors are fixed to the pipe using metal chains, straps or mounting rails. Most permanent ultrasonic flow meters are. As the ultrasonic sensors are simply clamped on the pipe surface, katronic ultrasonic flow meters can be installed without the need to break into pipelines.
It uses the ultrasonic wave emitted by the sensor to propagate in the flowing fluid. Clamp on ultrasonic flow meter installation guidelines. Pipes, allowing for installation without system shutdown, and produces no pressure drop.
The flexim f601 ultrasonic liquid flow meter measures liquid and energy flow in a pipe. 1.7 additional hardware that may be required flex conduit may be required to connect transducer to rigid conduit. • install this product as specified in the installation section of this manual per applicable local and national codes.
The grease is used to eliminate any gaps between the transducer and the pipe wall. Clamp on ultrasonic flow meter working principle. This is particularly true for applications where the flowmeter needs to be installed in an existing facility where the piping layout is already completed and in place.
The f601 has data logging capabilities and a digital display for instantaneous flow measurements. The best placement on a horizontal pipe is either the 2:00 to 4:00 or 8:00 to 10:00 positions for two (2) cross (reflect) or four (4) cross (double reflect) mode, or one sensor at 9:00 and one sensor at 3:00 for one (1) cross mode (direct). Clamp on ultrasonic flow meter adopts the measurement principle of time difference method.
The sound wave propagation speed in the downstream direction will increase, and the backward direction will decrease.
